66 BBV28581 05/2010
Configuration Mode - Complete menu (FULL)
Code
Name/Description Adjustment range Factory setting
FUn-
Function menu (continued)
Stt-
Stop configuration menu
Stt
M Type of stop
rMP
rMP
FSt
nSt
Stop mode on disappearance of the run command and appearance of a stop command
v Ramp stop
v Fast stop
v Freewheel
nSt
M Freewheel stop assignment
nO
nO
L1L
L2L
L3L
L4L
The stop is activated when the input or the bit changes to 0. If the input returns to state 1 and the run
command is still active, the motor will only restart if Type of control tCC page 48
= 2C and 2 wire type
control tCt page 51
= LEL or PFO. If not, a new run command must be sent.
v Not assigned
v L1L: LI1 Active Low to stop
v L2L: LI2 Active Low to stop
v L3L: LI3 Active Low to stop
v L4L: LI4 Active Low to stop
FSt
M Fast stop assignment
nO
nO
L1L
L2L
L3L
L4L
v Not assigned
v L1L: LI1 Active Low to stop
v L2L: LI2 Active Low to stop
v L3L: LI3 Active Low to stop
v L4L: LI4 Active Low to stop
dCF
T
M Ramp divider
1 to 10
4
Visible only if Fast stop assignment FSt page 63 is not set to nO or if FSt is set to Type of stop Stt
page 66
.
The ramp that is enabled (Deceleration dEC page 45
or Deceleration 2 dE2 page 65) is then divided
by this coefficient when stop requests are sent.
Value 10 corresponds to a minimum ramp time.
Code
Name/Description Adjustment range Factory setting
FUn-
Function menu (continued)
rrS
M Reverse direction
nO
nO
LIH
L2H
L3H
L4H
LI1 to LI4: choice of the input assigned to the reverse command
v Function inactive
v L1h: L1 active high
v L2h: L2 active high
v L3h: L3 active high
v L4h: L4 active high
T
Parameter that can be modified during operation or when stopped.
I-O-
drC-
CtL-
FUN-
FLt-
COM-
