BBV28581 05/2010 127
Parameter index
(1)In = nominal drive current
Code Page Name Unit Possible value / Function Factory setting
User
setting
nCr 57
Rated motor current A (1)
0.25 to
1.5
-
according to
drive rating
nCU 41 Drive Power rating
nFd 79
Zero flow detection period nO
nM1
98
Com scanner read address
value 1
nM2
98
Com scanner read address
value 2
nM3
98
Com scanner read address
value 3
nM4
98
Com scanner read address
value 4
nMA1
97
Com scanner read address
parameter 1
-0C81
nMA2
97
Com scanner read address
parameter 2
- 219C
nMA3
97
Com scanner read address
parameter 3
-0
nMA4
97
Com scanner read address
parameter 4
-0
nPL 51
Logic inputs type -
POS
nEG
Positive
Negative
POS
nPr
46
57
Rated Motor Power
kW or
HP
--
according to
drive rating
nrd 59
Motor noise reduction
nO
YES
No
Yes
nO
nSP 57
Rated motor speed rpm 0 to 32767 -
according to
drive rating
nSt 66
Freewheel stop assignment
nO
L1L
L2L
L3L
L4L
No
L1L: LI1 active low
L2L: LI2 active low
L3L: LI3 active low
L4L: LI4 active low
nO
OLL
94
Overload fault management -
nO
YES
No
Yes
YES
OPL
94
Output Phase loss -
nO
YES
No
Yes
YES
Opr
39
Output power % - - -
-
PAU
74
PID auto/manual assignment
nO
L1H
L2H
L3H
L4H
No
L1h: LI1 active high
L2h: LI2 active high
L3h: LI3 active high
L4h: LI4 active high
nO
PEt 42
Process elapsed time 0.01 - - - -
PFL 59
Flux Profile % 0 to 100 20%
PIC
74
PID correction reverse -
nO
YES
No
Yes
nO
