40 BBV28581 05/2010
Monitoring mode MOn
Code
Name/Description
StAt
M Product status
This parameter shows the state of the drive and motor.
rdY
rUn
ACC
dEc
dCb
CLI
nSt
Obr
CtL
tUn
FSt
nLP
FrF
rEM
LOC
v Drive ready
v Drive running, the last six segments to the right of the code also indicate direction and speed.
v Acceleration, the last six segments to the right of the code also indicate direction and speed.
v Deceleration, the last six segments to the right of the code also indicate direction and speed.
v DC injection braking in progress
v Current limit, the four segments located on right down of display are blinking.
v Freewheel stop control
v Auto-adapted deceleration
v Controlled stop on mains phase loss
v Auto-tuning in progress
v Fast stop
v No line power. When the control part is energized via the RJ45 connector and there is no power on the
main input and no run order is present.
v Drive is running and using the withdrawal reference LFF
v Remote configuration
v Local configuration
