Configuration Mode - Complete menu (FULL)
Code
Name/Description Adjustment range Factory setting
I_O-
Input Output menu (continued)
LO1-
LO1 Configuration menu (LO1-)
LO1
M LO1 assignment
nO
Allows to adapt the logic output to the application need.
Same values as r1.
See previous page.
When MdE = YES, output LO1 is forced to PMP (See page 78
).
LO1S
M LO1 status (output active level)
POS
WARNING
LOSS OF CONTROL
When LO1S = nEG and LO1 is set to FLt, The output will be active when the drive will detect a fault.
The drive status will not be detected if the wiring is damaged for any reason.
Do not select "nEG" unless you are sure that your signal will be present in any case.
Failure to follow these instructions can result in death, serious injury, or equipment damage.
POS
nEG
v Positive : hight activation level
v Negative : low activation level
T
Parameter that can be modified during operation or when stopped.
