98 BBV28581 05/2010
Configuration Mode - Complete menu (FULL)
Code
Name/Description Adjustment range Factory setting
COM-
Communication menu (continued)
ISA-
Input scanner access menu (values are expressed in hexadecimal)
nM1
M Com scanner read address value 1
ETA VALUE
Value of the 1st input word
nM2
M Com scanner read address value 2
RFRD value
Value of the 2nd input word
nM3
M Com scanner read address value 3
8000
Value of the 3rd input word
nM4
M Com scanner read address value 4
8000
Value of the 4rd input word
OSA-
Output scanner access menu (values are expressed in hexadecimal)
nC1
T
M Com scanner write address value 1
CMD value
Value of the 1st output word
nC2
T
M Com scanner write address value 2
LFRD value
Value of the 2nd output word
nC3
T
M Com scanner write address value 3
8000
Value of the 3rd output word
nC4
T
M Com scanner write address value 4
8000
Value of the 4th output word
T
Parameter that can be modified during operation or when stopped.
I-O-
drC-
CtL-
FUN-
FLt-
COM-
