70 BBV28581 05/2010
Configuration Mode - Complete menu (FULL)
Code
Name/Description Adjustment range Factory setting
FUn-
Function menu (continued)
PSS-
Preset speed menu
PS2
M 2 Preset speeds
nO
nO
L1H
L2H
L3H
L4H
v Function inactive
v L1h: LI1 active high
v L2h: LI2 active high
v L3h: LI2 active high
v L4h: LI4 active high
PS4
M 4 Preset speeds
nO
as PS2
PS8
M 8 Preset speeds
nO
as PS2
SP2
T
M Preset speed 2
0 to 400 Hz 10 Hz
Visible only if 2 Preset speeds PS2 is not set to nO.
SP3
T
M Preset speed 3
0 to 400 Hz 15 Hz
Visible only if 4 Preset speeds PS4 is not set to nO.
SP4
T
M Preset speed 4
0 to 400 Hz 20 Hz
Visible only if 2 Preset speeds PS2 and 4 Preset speeds PS4 are not set to nO.
SP5
T
M Preset speed 5
0 to 400 Hz 25 Hz
Visible only if 8 Preset speeds PS8 is not set to nO.
SP6
T
M Preset speed 6
0 to 400 Hz 30 Hz
Visible only if 2 Preset speeds PS2 and 8 Preset speeds PS8 are not set to nO.
SP7
T
M Preset speed 7
0 to 400 Hz 35 Hz
Visible only if 4 Preset speeds PS4 and 8 Preset speeds PS8 are not set to nO.
SP8
T
M Preset speed 8
0 to 400 Hz 40 Hz
Visible only if 2 Preset speeds PS2, 4 Preset speeds PS4 and 8 Preset speeds PS8 are not set to nO.
JPF
T
M Skip frequency
0 to 400 Hz 0 Hz
v This parameter prevents prolonged operation around the regulated frequency. This function can be used
to prevent a critical speed, which would cause resonance, being reached. Setting the function to 0 renders
it inactive.
T
Parameter that can be modified during operation or when stopped.
