Reference Manual
00809-0100-4021, Rev DA
November 2004
Rosemount 3144P
1-6
ROSEMOUNT 3144P
AND ROSEMOUNT 3144 /
3244MV DIFFERENCES
The following table identifies the differences between the Rosemount 3144P
and Rosemount 3144 and 3244MV Temperature Transmitters.
Improved Rosemount 3144P Previous Rosemount 3144 and 3244MV
Field Device Revision number 3 Standard 3144P: Dev v3, DD v2
3144P SIS: Dev v1, DD v1 (for SIS)
Software Revision number 3 Software Revision number 1
Added sensor input types: DIN Type L, DIN
Type U, and extended temperature range of
Type N
NA
Uses custom-configurable alarm limits Analog output and alarm levels can be ordered
to be NAMUR-compliant with option codes A1
and CN
Improved 2- and 3-wire EMF compensation NA
First Good Temperature is available as a
device variable
NA
2-wire fixed lead correction is available NA
Enhanced EMI rejection and filtering resulting
in unmatched stability in process measurement
NA
Dual-sensor configuration is field selectable Rosemount 3144 – single sensor
Rosemount 3244MV – dual-sensor configuration
