MERLIN LEGENDCommunications System Release 6.1
System Planning
555-661-112
Issue 1
August 1998
NI-1 BRI Provisioning
Page H-2Lucent Technologies 5ESS Switch Translations
H
Lucent Technologies 5ESS
Switch Translations H
For the Lucent Technologies 5ESS switch, Capability Package “S” includes
alternate voice/circuit-switched data on two B-channels. It also supports Calling
Number Identification on data and voice connections. Please note that in order to
have simultaneous calls on the two B-channels, two Directory Numbers (DNs)
must be assigned with this package.
The Lucent Technologies 5ESS switch also allows alternate voice and data
hunting on one DN using the Series Completion feature.
ISDN Capability Package “S” H
The information listed below provides the DN translations that define Capability
Package “S”, and the screens and fields that must be programmed.
The information provided shows the translations for one Digital Subscriber Line
(DSL) and two DNs. For multiple DSLs/DNs, the CO will duplicate these screens
and enter the applicable DSL and DN values as needed.
ISDN Ordering Code: Capability S H
VIEW 23.2 H
DN1 Translations H
Fields that must be programmed on Screens 1, 2, 3 and 4:
1. DSL TN <C plus
Telephone number
>
9. ASSOC <U>
11. OE <
enter OE and type
>
14. D ISCN <
enter value
>
15. DSERV <SX>
16. B1SERV <DMD>
17. B2SERV <DMD>
18. NT1 TYPE <
enter NT1 type
>
20. DSL CLS <STD>
21. RSTR MP <N>
22. MDPKT <0>
23. MTERM <2>
42. USPID <
enter value
>
43. MAXBCHL <2>
44. ACT USER <Y>
